产品概述:
TLG连续式与TJG间歇式型高浓除渣器能有效的去除纸浆中的渣滓，防止后续设备出现磨损。由于特殊优化的进浆口，因此这种除渣器能有效地去除沙子、玻璃片、订书钉等重杂质。采用内衬陶瓷锥体，可大大增强除渣器的耐磨性。独特设计的冲洗水装置可通过冲洗水最大限度减少纤维流失。一段到二段的无泵式运行能大大降低维护成本。经过两段除渣器的处理，能将浆料中的砂子等重杂质提早分离出来。更改产量只需更换进浆头，设备其它部件无需更换。
Production Introduction
TLG continuous type and TJG intermittent type high consistency centricleaner can remove the reject and prevent the subsequent equipment from abrasion effectively. Due to the specially optimized pulp inlet, the centricleaner can remove the heavy rejects such as sand, glass chips, staples, etc. The wear resistance of centricleaner can be greatly enhanced by using ceramic cone. The unique design of flushing water device can minimize fiber loss through flushing water. The TLG and TJG high consistency centricleaner can operate from one to two stage without pump,which can reduce the initial investment and the maintenance cost greatly . After the treatment of two-stage centricleaner, the heavy reject such as sand in the pulp can be separated early. For changing the output, only the feed head needs to be replaced, and other parts of the equipment do not need to be replaced.
主要技术参数
Main Parameter
规格型号 Specification | 400-10 | 400-12 | 400-15 | 400-18 |
进浆浓度 | 0-4.5 | |||
流量 Feeding Flow (L/min) | 2800-3200 | 3000-3600 | 3800-4500 | 5000-6000 |
规格型号 Specification | 600-15 | 600-18 | 600-21 | 600-25 |
进浆浓度 | 0-4.5 | |||
流量 Feeding Flow (L/min) | 6000-8500 | 8600-11000 | 10000-12700 | 12000-13700 |
