造纸磨浆机 秸秆稻草桉木竹片制浆设备 供应纸浆高浓磨浆机

价格:￥65200.00/件
起订:1件
供应:5000件
发货:10天内

立即购买

商品属性

订货号按需定制

加工定制是

货号按需定制

品牌ZY/增益

型号按需定制

用途磨浆

别名高浓磨

是否跨境出口专供货源否

商品描述



高浓度节能型磨浆机是现代造纸业处理化学浆、半化学机械浆、机械浆、冷浸法高得率浆及纤维板料研磨的理想设备。高浓磨对浆料的适用范围较广，无论是树种复杂，材料差异较大的浆料，还是木材加工后剩余的边角料，以及刨花、锯屑、节子浆、棉秆、麻秆、灌木、枝桠材、稻麦草、芦苇、麻类多种商品浆板、废纸、甘蔗渣、龙须草等，都能够以其较高的旋线速度及适当磨片间隙分离成优良纤维。高浓磨浆，对纤维切断少，分丝帚化效果显著，而且纤维的柔韧性好，可有效保护阔叶木和草类等短纤维的纤维长度。







High concentration energy-saving pulping machine is an ideal equipment for treating chemical pulp, semi-chemical mechanical pulp, mechanical pulp, high yield pulp by cold immersion method and grinding fiberboard materials in modern paper industry. High consistency refiner has a wide range of applications for pulps, such as pulps with complex tree species and large material differences, or residual corner materials after wood processing, as well as particles, sawdust, knotweed pulp, cotton stalk, hemp stalk, shrubs, branches, rice straw, reeds, hemp, various commodity pulp boards, waste paper, bagasse, Longxu grass, etc. They can be separated into high quality fibers with their high rotational speed and suitable grinding clearance. High consistency pulping can effectively protect the fiber length of short fibers such as broad-leaved trees and grasses.



高浓度节能磨浆机技术参数
Technical parameter of ZDPH high consistency energy-saving refiner


生产能力（t/d） Production capacity	15-20	20-30	30-50	50-80
磨盘直径(mm) Grinding disc diameter	600	700	800	915
磨盘转速(r/min) Disc rotation speed	1480	1480	1480	1480
磨浆浓度(%) Pulping concentration	30-70	30-70	30-70	30-70
主电机功率(kw) Main motor power	75-110	110-160	160-220	220-355
喂料形式 Feeding form	205单螺旋强制喂料 205 Single screw forced feeding	220	300	420
喂料电机功率(kw) Feeding motor power	3	4	5.5	7.5
